- General Information
- Manufacturer
- PANDUIT CORP
- Manufacturer Website Address
- http://www.panduit.com
- Brand Name
- PanNet
- Product Line
- TX6
- Product Type
- Network Cable
The TX6™ Cat 6 U/UTP copper cable is constructed of 24 AWG copper conductors with FEP/HDPE insulation. The copper conductors are twisted in pairs. All four pairs are surrounded by a PVC flame-retardant jacket. The violet, plenum (CMP) cable is supplied 1,000 feet (305 meters) to an easy pay-out carton.
- Technical Information
- Cable Type
- Category 6
- Cable Length
- 1000.66 ft
- Connector Type on First End
- Bare Wire
- Connector Type on Second End
- Bare Wire
- Shielding
- No
- Jacket Type
- CMP
- CSA FT6
- Device Supported
- Network Device
- American Wire Gauge
- 24 AWG
- Number of Pairs
- 4
- Features
- Flame Retardant
- PoE
- Bendable
- Break Resistant
- Physical Characteristics
- Product Color
- Violet
- Product Material
- Copper
- Insulation Material
- Polyolefin
- Fluorinated Ethylene Propylene (FEP)
- Jacket Material
- Fluorinated Ethylene Propylene (FEP)
- Low Smoke Fire Resistant Polyvinyl Chloride (LS FR-PVC)
- Material Details
Copper - Cable
Copper - Conductor
