- General Information
- Manufacturer
- GeoVision, Inc
- Manufacturer Website Address
- http://www.geovision.com.tw
- Brand Name
- GeoVision
- Product Type
- Elevator Controller
GV-EV48 is an elevator controller designed to control access of 1 elevator with a maximum of 48 floors. Up to 2 GV-Readers / GV-GF Fingerprint Readers can be connected to GV-EV48 using RS-485 connection and network connection. GV-EV48 can recognize identification cards and grant access to the authorized floors only.
- Physical Characteristics
- Height
- 6.7"
- Width
- 8.3"
- Depth
- 2.2"
- Weight (Approximate)
- 1.34 lb
- Miscellaneous
- Package Contents
- GV-EV48 Elevator Controller
- 12V DC / 3A Power Adaptor
- Power Cord
- Battery Cable
- 2GB Micro SD Card
- Additional Information
- System Requirements:
- GV-ASManager Version: GV-ASManager V4.1 or later
- CPU: 32-bit ARM7TDMI
- Number of User Cards: 40,000 cards
- Event Buffer: 1,000,000 events and log data
- Power: AC 100~250 V , 50~60Hz
- RS-485 Interface: 1 RS-485 interface only for GV-Readers and GV-GF Fingerprint Readers (max. 2 readers)
- TCP/IP Interface: 1 TCP/IP interface for GeoVision network readers
- Communication: TCP/IP
- Battery: Built-in battery
- Output: 24 relay outputs (30VDC, 1A; 125V AC, 0.3A)
- Operating Temperature 0~65°C / 32 ~ 149°F
- Operating Humidity 10% ~ 90% RH (non-condensing)
- Application/Usage
- Access Control
- Certifications & Standards
- CE
- FCC
- Environmentally Friendly
- Yes
- Environmental Compliance
- Restriction of Hazardous Substances (RoHS)
